Dahua 2MP 60x Starlight IR AI Network Positioning System - PTZ85260-HNF-WA

Camera

Image Sensor

1/1.8" CMOS

Max. Resolution

1920 (H) × 1080 (V)

Effective Pixels

2MP

ROM

8GB

RAM

4GB

Electronic Shutter Speed

1/1–1/100000s

Scanning System

Progressive

Min. Illumination

Color: 0.001Lux@F1.4
B/W: 0.0001Lux@F1.4
0Lux (IR light on)

IR Distance

400 m (1312.34 ft)

IR On/Off Control

Zoom Prio/Manual/SmartIR

IR LEDs Number

8

Wiper

Support

Lens

Focal Length

5.6 mm–336 mm

Max. Aperture

F1.4–F4.5

Field of View

H: 1.4°–64.9°; V: 1.0°–38.0°; D: 1.7°–72.2°

Optical Zoom

60x

Focus Control

Auto/Semi-Auto/Manual

Close Focus Distance

0.5 m–2 m (1.64 ft–6.56 ft)

Iris Control

Auto

DORI Distance

Detect

Observe

Recognize

Identify

6720m (22047.24ft)

2666.7m (8749.02ft)

1344m (4409.45ft)

672m (2204.72ft)

PTZ

Pan/Tilt Range

Pan: 0°–360°; Tilt: -90°– 45°

Manual Control Speed

Pan: 0.1°–160°/s; Tilt: 0.1°–60°/s

Preset Speed

Pan: 160°/s; Tilt:60°/s

Presets

300

Tour

8 (up to 32 presets per tour)

Pattern Number

5

Scanning Number

5

Speed Adjustment

Support

Power-off Memory

Support

Idle Motion

Preset/Tour/Pattern/Scanning

Protocol

DH-SD
Pelco-P/D (auto recognition)

Artificial Intelligence

Video Metadata

Support human body, human face, motor vehicle

and non-motor vehicle image capture and

atributes extracton

Perimeter Protection

Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

Auto Tracking

Support

General Intelligence

Event Trigger

Motion detection, video tampering, scene changing, network disconnection, IP address conflict, illegal access, and storage anomaly

General IVS

Object abandoned/missing

Video

Compression

H.265/H.264H/H.264B/H.264/MJPEG (sub stream)

Streaming Capability

3 streams

Resolution

1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); CIF (352 × 288)

Frame Rate

Main stream: 1080P/1.3M/720P (1–25/30 fps)
Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 1080P/1.3M/720P (1–25/30 fps), D1/CIF (1–25/30 fps)

Bit Rate Control

Variable Bit Rate/Constant Bit Rate

Bit Rate

H.264: 1792 kbps–9216 kbps
H.265: 512 kbps–5632 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Support

WDR

120dB

HLC

Support

White Balance

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp

Gain Control

Auto/Manual

Noise Reduction

2D/3D

Motion Detection

Support

Region of Interest (RoI)

Support

Electronic Image Stabilization (EIS)

Support

Defog

Optical

Digital Zoom

16x

Flip

0°/180°

Privacy Masking

Up to 24 areas

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014

Audio

Compression

G.711A; G.711Mu; G.726; AAC; G.722.1; G.729; PCM; MPEG2-Layer2

Port

Audio In

1

Audio Out

1

Alarm

7/2

Analog Output

1 BNC

RS-485

1

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE

Interoperability

ONVIF; CGI

Streaming Method

Unicast/Multicast

User/Host

20 (Total bandwidth 64M)

Edge Storage

FTP; Micro SD card (256G)

Browser

IE7 and newer versions
Chrome 42 and older versions
Firefox 52 and older versions
Safari

Management Software

Smart Player; Smart PSS; DSS; Easy4ip

Mobile Phone

IOS/Android/Windows Phone

Power

Power Supply

DC36V/2.23A ± 25%

Power Consumption

28.7W
61.6W (IR LEDs on and PTZ moving)

Environment

Operating Temperature

-40°C to -70°C (-40°F to +158°F)

Operating Humidity

≤95% RH

Ingress Protection

IP67; TVS 6000V lightning protection; surge protection

Structure

Casing

Metal + plastic

Dimensions

210.7 mm × 399.3 mm × 517.0 mm (8.30" × 15.72" × 20.35")

Net Weight

14.9 kg (32.85 lb)

Gross Weight

21.4 kg (47.18 lb)
